The APOE03 Power over Ethernet (PoE) Passive Injector delivers both data and electrical power to passive PoE devices using a single Ethernet cable. Using PoE you eliminate the need to place an Ethernet device, such as a wireless access point or IP Camera giving you more freedom.
The installation is simple and easy for APOE03 it does not require any tools or software. Plug the APOE03 into a power outlet and connect the APOE03 to your passive PoE device using any standard Ethernet cable. Once APOE03 setup has been completed the output power is compatible to any 5VDC, 12VDC, 24VDC, 48VDC, 57VDC (Max. 48W) Passive PoE-enable device.
מפרט טכני:
| Interfaces | |
|---|---|
| RJ45 Ports | (2) 100 Mbps |
| Number of PoE Ports | 1 pcs |
| PoE Out Standards | Passive PoE |
| Power | |
| Power Method | AC/DC Adapter |
| Power Supply | External x2 AC/DC Adapter |
| Supported Input Voltage | 5 – 57 V DC |
| Power Connector | DC Plug 2.1 x 5.5 mm, Terminal Block |
| Power Adapter | |
| Ehternet Ports | 100 Mbps |
| Ethernet Powering | 2-Pair |
| Package Contains | |
| External Power Supply | Not Included |
